Air curtain Optima K

Air curtain for cold rooms with temperatures above 0º and which has been designed with a tangential turbine, which provides a homogeneous air flow. It is equipped with a stepless regulator, which allows the regulation of the curtain not to be carried out in stages, but to calibrate the air speed continuously, adapting it to each installation.

It includes a Stepless regulator, with a quick start Kick-start function, which allows the supply air speed to be varied continuously (without jumps).

Basic Specifications

Maximum range

Up to 3 m

Airflow

1650 - 3190 m3/h

Length

1 m to 2 m

Fans

Tangential proportional with low noise twisted profile turbine

Chamber temperature

* >0ºC

Protection grade

IP20

Casing

Galvanised Steel

Grille type

Hexagonal perforated surface avoiding intensive maintenance

Outlet vanes

Aluminium, airfoil type

Finishes

RAL 9016 standard | Other colors on request

Control

Stepless control with kick-start function

[*] From 0ºC to -25ºC only in certain conditions.

Technical Data Filters

Filters

Heating

Unheated

Length

1000

1500

2000

All

Frequency

50Hz

Dimensions

Accessories

Airtècnics offers a wide range of accessories designed to complement and optimize any air curtain installation, including brackets, sensors, smart control solutions, and customization options tailored to each project.

Primary control

Silentblock - Ceiling

IP Protection

External Signals

Maxwell without regulation
