Air curtain recessed Windbox SB-BB
This curtain from the standard range is specially designed for installation in false ceilings. It has a white aluminium profile frame that integrates the discharge diffuser and the suction grille, which requires no maintenance.
It is a curtain that generates very little noise and, depending on the model, it can be provided with heating by a hot water battery or an electric battery with three regulation stages. Includes Clever control.
- Self-supporting casing construction made of galvanized steel plate, ready to be installed recessed in a false ceiling.
- Inlet grille (free of maintenance) made with aluminium profiles and blow-out nozzle, integrated in a single white frame colour RAL 9016. Other colours are available on request.
- Anodized aluminium outlet vanes, airfoil shaped, adjustable in both directions.
- EC Double-inlet centrifugal fans driven by an external rotor motor and low noise level, with very low consumption efficency fans.
- “P” type with water heated coil. “E” type with electrical shielded elements, three stages with integrated regulation. “A” type without heating, air only. Optional expansion DX coil.
- Advanced Plug&Play control. Includes: Advanced PRO control with LCD display and integrated thermostat, door contact, 7m RJ11 cable and remote control. Optional: intelligent Clever Pro Control (automatic, programmable, ModBus for PKC, timer, etc.)
Model Nominal Airflow
m³/hRecommended Installation Range
mNominal Airflow 208V
m³/hRSB 1000 A 3060 3,5-5 0 RSB 1500 A 4080 3,5-5 0 RSB 2000 A 6120 3,5-5 0 RSB 2500 A 7140 3,5-5 0 RBB 1000 A 4020 4-7 - RBB 1500 A 5360 4-7 - RBB 2000 A 8040 4-7 - RBB 2500 A 9380 4-7 - Model Nominal Airflow
m³/hElectrical Heating Capacity 400Vx3
kWRecommended Installation Range
mNominal Airflow 208V
m³/hRSB 1000 E 3060 5/10/15 3,5-5 0 RSB 1500 E 4080 7,5/15/22,5 3,5-5 0 RSB 2000 E 6120 10/20/30 3,5-5 0 RSB 2500 E 7140 12/22/34 3,5-5 0 RBB 1000 E 4020 6/15/21 4-7 - RBB 1500 E 5360 8/19/27 4-7 - RBB 2000 E 8040 12/30/42 4-7 - RBB 2500 E 9380 16/30/46 4-7 - Model Nominal Airflow
m³/hRecommended Installation Range
mHeating Capacity 80/60ºC (kW)
kWHeating Capacity 60/40ºC (kW)
kWHeating Capacity 50/40ºC
kWNominal Airflow 208V
m³/hRSB 1000 P86 2910 3,5-5 15.58 - - 0 RSB 1500 P86 3880 3,5-5 19.71 - - 0 RSB 2000 P86 5820 3,5-5 31 - - 0 RSB 2500 P86 6790 3,5-5 38.97 - - 0 RSB 1000 P64 2910 3,5-5 - 12.44 - 0 RSB 1500 P64 3880 3,5-5 - 18.55 - 0 RSB 2000 P64 5820 3,5-5 - 22.84 - 0 RSB 2500 P64 6790 3,5-5 - 31.79 - 0 RSB 1000 P54 2910 3,5-5 - - 14.47 0 RSB 1500 P54 3880 3,5-5 - - 21.19 0 RSB 2000 P54 5820 3,5-5 - - 30.77 0 RSB 2500 P54 6790 3,5-5 - - 36.94 0 RBB 1000 P86 3750 4-7 18,21 - - - RBB 1000 P64 3750 4-7 - 15,16 - - RBB 1000 P54 3750 4-7 - - 16,48 - RBB 1500 P86 5000 4-7 26,46 - - - RBB 1500 P64 5000 4-7 - 21,87 - - RBB 1500 P54 5000 4-7 - - 24,15 - RBB 2000 P86 7500 4-7 38,44 - - - RBB 2000 P64 7500 4-7 - 31,13 - - RBB 2000 P54 7500 4-7 - - 35,04 - RBB 2500 P86 8750 4-7 46,38 - - - RBB 2500 P64 8750 4-7 - 38,96 - - RBB 2500 P54 8750 4-7 - - 42,12 - Model Nominal Airflow
m³/hRecommended Installation Range
mNominal Airflow 208V
m³/hRSB 1000 A 3060 3,5-5 0 RSB 1500 A 4080 3,5-5 0 RSB 2000 A 6120 3,5-5 0 RSB 2500 A 7140 3,5-5 0 RBB 1000 A 4020 4-7 - RBB 1500 A 5360 4-7 - RBB 2000 A 8040 4-7 - RBB 2500 A 9380 4-7 - Model Nominal Airflow
m³/hElectrical Heating Capacity 400Vx3
kWRecommended Installation Range
mNominal Airflow 208V
m³/hRSB 1000 E 3060 5/10/15 3,5-5 0 RSB 1500 E 4080 7,5/15/22,5 3,5-5 0 RSB 2000 E 6120 10/20/30 3,5-5 0 RSB 2500 E 7140 12/22/34 3,5-5 0 RBB 1000 E 4020 6/15/21 4-7 - RBB 1500 E 5360 8/19/27 4-7 - RBB 2000 E 8040 12/30/42 4-7 - RBB 2500 E 9380 16/30/46 4-7 - Model Nominal Airflow
m³/hRecommended Installation Range
mHeating Capacity 80/60ºC (kW)
kWHeating Capacity 60/40ºC (kW)
kWHeating Capacity 50/40ºC
kWNominal Airflow 208V
m³/hRSB 1000 P86 2910 3,5-5 15.58 - - 0 RSB 1500 P86 3880 3,5-5 19.71 - - 0 RSB 2000 P86 5820 3,5-5 31 - - 0 RSB 2500 P86 6790 3,5-5 38.97 - - 0 RSB 1000 P64 2910 3,5-5 - 12.44 - 0 RSB 1500 P64 3880 3,5-5 - 18.55 - 0 RSB 2000 P64 5820 3,5-5 - 22.84 - 0 RSB 2500 P64 6790 3,5-5 - 31.79 - 0 RSB 1000 P54 2910 3,5-5 - - 14.47 0 RSB 1500 P54 3880 3,5-5 - - 21.19 0 RSB 2000 P54 5820 3,5-5 - - 30.77 0 RSB 2500 P54 6790 3,5-5 - - 36.94 0 RBB 1000 P86 3750 4-7 18,21 - - - RBB 1000 P64 3750 4-7 - 15,16 - - RBB 1000 P54 3750 4-7 - - 16,48 - RBB 1500 P86 5000 4-7 26,46 - - - RBB 1500 P64 5000 4-7 - 21,87 - - RBB 1500 P54 5000 4-7 - - 24,15 - RBB 2000 P86 7500 4-7 38,44 - - - RBB 2000 P64 7500 4-7 - 31,13 - - RBB 2000 P54 7500 4-7 - - 35,04 - RBB 2500 P86 8750 4-7 46,38 - - - RBB 2500 P64 8750 4-7 - 38,96 - - RBB 2500 P54 8750 4-7 - - 42,12 -
