Air curtain Windbox with Kleenfan technology

Windbox robust, timeless design and great versatility air curtain with photocatalysis Kleenfan technology that disinfects and purifies the air, for commercial and industrial doors

Air curtain Windbox with Kleenfan technology
Air curtain Windbox with Kleenfan technology
Previous Next


  • It combines a dual patented disinfection and purification technology through the generation of hydroxyl radicals OH· and the effect of photocatalysis.
  • Innovative active Wellisair technology with efficient production of hydroxyl radicals, harmless to humans, which disinfect through a chain reaction both the air and the surfaces. Through Advanced Oxidation Processes (POA) they eliminate up to 99.9% of pathogenic microorganisms (viruses and bacteria), improve air quality (reducing volatile organic compounds and suspended particles) and eliminate odors.
  • Kleenfan technology with photocatalytic disinfectant action fans. UV-A rays act on the titanium dioxide in the turbine generating Reactive Oxygen Species (ROS) that, through oxidation/reduction reactions, eliminate a wide range of organisms reducing them up to 99.9%.
    It mineralizes most of the pollutants present in urban areas produced by vehicles and industry (NOx, SOx, COx, formaldehydes, VOCs, etc.).
  • Air quality indicator with 4 status levels and hydrogen peroxide biocide cartridge replacement alarm (approximately every 3 months).
  • Includes Advanced Clever Control with disinfection program running 24 hours a day, 4-level indicator of air quality and replacement alarm of the hydrogen peroxide biocidal cartridge (about 3 months duration, depending on conditions). Plug & Play, programmable, intelligent, automatic, energy saving, Modbus RTU by PLC…).
  • Self-supporting galvanized steel housing, finished with white RAL 9016 epoxy-polyester paint as standard. Other colors or stainless steel available upon request.
  • Micro-perforated front absorber grille with easy-service regenerable filter functions. You do not need pre-filters.
  • Linear discharge diffusers with airfoil-type anodized aluminum slats, adjustable 15º in both directions.
  • EC double-inlet centrifugal fans with very low consumption and noise level external rotor motors. 5 speed selector.
  • The "P" models incorporate a hot water coil. The "E" models incorporate a three-stage electric coil with regulation included. Models "A" are not heated, just air. Optional "DX" with direct expansion battery.

Datasheet Windbox FC
Air Curtains Catalogue 2019

 BIM Files
 Request more information
  • 50Hz
  • 60Hz
    • Unheated
    • Electrical Heating
    • Water Heating
    Model
    Nominal Airflow
    mÂł/h
    Recommended Installation Height
    m
    ECM 1000 A FC18402,5-3,8
    ECM 1500 A FC27602,5-3,8
    ECM 2000 A FC36802,5-3,8
    ECM 2500 A FC46002,5-3,8
    ECM 3000 A FC55202,5-3,8
    ECG 1000 A FC27003-4,2
    ECG 1500 A FC36003-4,2
    ECG 2000 A FC54003-4,2
    ECG 2500 A FC63003-4,2
    ECG 3000 A FC72003-4,2
    Model
    Nominal Airflow
    mÂł/h
    Electrical Heating Capacity 400Vx3
    kW
    Recommended Installation Height
    m
    ECM 1000 E FC18403/6/92,5-3,8
    ECM 1500 E FC27604/8/122,5-3,8
    ECM 2000 E FC36806/12/182,5-3,8
    ECM 2500 E FC46006/12/182,5-3,8
    ECM 3000 E FC55208/16/242,5-3,8
    ECG 1000 E FC27005/10/153-4,2
    ECG 1500 E FC36007,5/15/22,53-4,2
    ECG 2000 E FC540010/20/303-4,2
    ECG 2500 E FC630010/20/303-4,2
    ECG 3000 E FC720010/20/303-4,2
    Model
    Nominal Airflow
    mÂł/h
    Heating Capacity 80/60ÂșC
    kW
    Heating Capacity 60/40ÂșC
    kW
    Heating Capacity 50/40ÂșC
    kW
    Recommended Installation Height
    m
    ECM 1000 P86 FC17209.38--2,5-3,8
    ECM 1500 P86 FC258014.58--2,5-3,8
    ECM 2000 P86 FC344021.12--2,5-3,8
    ECM 2500 P86 FC430027.53--2,5-3,8
    ECM 3000 P86 FC516033.99--2,5-3,8
    ECG 1000 P86 FC255011.04--3-4,2
    ECG 1500 P86 FC340016.02--3-4,2
    ECG 2000 P86 FC510024.92--3-4,2
    ECG 2500 P86 FC595031.16--3-4,2
    ECG 3000 P86 FC680037.35--3-4,2
    ECM 1000 P64 FC1720-8.77-2,5-3,8
    ECM 1500 P64 FC2580-14.02-2,5-3,8
    ECM 2000 P64 FC3440-18.7-2,5-3,8
    ECM 2500 P64 FC4300-23.33-2,5-3,8
    ECM 3000 P64 FC5160-29.05-2,5-3,8
    ECG 1000 P64 FC2550-10.42-3-4,2
    ECG 1500 P64 FC3400-15.47-3-4,2
    ECG 2000 P64 FC5100-22.29-3-4,2
    ECG 2500 P64 FC5950-26.61-3-4,2
    ECG 3000 P64 FC6800-32.1-3-4,2
    ECM 1000 P54 FC1720--8.742,5-3,8
    ECM 1500 P54 FC2580--14.712,5-3,8
    ECM 2000 P54 FC3440--19.132,5-3,8
    ECM 2500 P54 FC4300--24.952,5-3,8
    ECM 3000 P54 FC5160--30.542,5-3,8
    ECG 1000 P54 FC2550--10.563-4,2
    ECG 1500 P54 FC3400--16.373-4,2
    ECG 2000 P54 FC5100--23.153-4,2
    ECG 2500 P54 FC5950--28.763-4,2
    ECG 3000 P54 FC6800--34.033-4,2
    • Unheated
    • Electrical Heating
    • Water Heating
    Model
    Nominal Airflow
    mÂł/h
    Recommended Installation Height
    m
    ECM 1000 A FC18402,5-3,8
    ECM 1500 A FC27602,5-3,8
    ECM 2000 A FC36802,5-3,8
    ECM 2500 A FC46002,5-3,8
    ECM 3000 A FC55202,5-3,8
    ECG 1000 A FC27003-4,2
    ECG 1500 A FC36003-4,2
    ECG 2000 A FC54003-4,2
    ECG 2500 A FC63003-4,2
    ECG 3000 A FC72003-4,2
    Model
    Nominal Airflow
    mÂł/h
    Electrical Heating Capacity 400Vx3
    kW
    Recommended Installation Height
    m
    ECM 1000 E FC18403/6/92,5-3,8
    ECM 1500 E FC27604/8/122,5-3,8
    ECM 2000 E FC36806/12/182,5-3,8
    ECM 2500 E FC46006/12/182,5-3,8
    ECM 3000 E FC55208/16/242,5-3,8
    ECG 1000 E FC27005/10/153-4,2
    ECG 1500 E FC36007,5/15/22,53-4,2
    ECG 2000 E FC540010/20/303-4,2
    ECG 2500 E FC630010/20/303-4,2
    ECG 3000 E FC720010/20/303-4,2
    Model
    Nominal Airflow
    mÂł/h
    Heating Capacity 80/60ÂșC
    kW
    Heating Capacity 60/40ÂșC
    kW
    Heating Capacity 50/40ÂșC
    kW
    Recommended Installation Height
    m
    ECM 1000 P86 FC17209.38--2,5-3,8
    ECM 1500 P86 FC258014.58--2,5-3,8
    ECM 2000 P86 FC344021.12--2,5-3,8
    ECM 2500 P86 FC430027.53--2,5-3,8
    ECM 3000 P86 FC516033.99--2,5-3,8
    ECG 1000 P86 FC255011.04--3-4,2
    ECG 1500 P86 FC340016.02--3-4,2
    ECG 2000 P86 FC510024.92--3-4,2
    ECG 2500 P86 FC595031.16--3-4,2
    ECG 3000 P86 FC680037.35--3-4,2
    ECM 1000 P64 FC1720-8.77-2,5-3,8
    ECM 1500 P64 FC2580-14.02-2,5-3,8
    ECM 2000 P64 FC3440-18.7-2,5-3,8
    ECM 2500 P64 FC4300-23.33-2,5-3,8
    ECM 3000 P64 FC5160-29.05-2,5-3,8
    ECG 1000 P64 FC2550-10.42-3-4,2
    ECG 1500 P64 FC3400-15.47-3-4,2
    ECG 2000 P64 FC5100-22.29-3-4,2
    ECG 2500 P64 FC5950-26.61-3-4,2
    ECG 3000 P64 FC6800-32.1-3-4,2
    ECM 1000 P54 FC1720--8.742,5-3,8
    ECM 1500 P54 FC2580--14.712,5-3,8
    ECM 2000 P54 FC3440--19.132,5-3,8
    ECM 2500 P54 FC4300--24.952,5-3,8
    ECM 3000 P54 FC5160--30.542,5-3,8
    ECG 1000 P54 FC2550--10.563-4,2
    ECG 1500 P54 FC3400--16.373-4,2
    ECG 2000 P54 FC5100--23.153-4,2
    ECG 2500 P54 FC5950--28.763-4,2
    ECG 3000 P54 FC6800--34.033-4,2
  • Images
  • Dimensions
  • 3D View
Air curtain Windbox with Kleenfan technology - Dimensions
Products
Air Curtains
Air Purifier and Disinfection Units
Air Handling Units
Heat Recovery Units
Ventilation Units
Axial Fans
Radial fans
Centrifugal Fans
In Line Fans
Exhaust Fans Units
Cross-Flow Fans
Fan Heaters
Filters and Filter Units
Dampers and Shutters
Rotary Actuators
Regulation
Pressure Switches and Sensors

Air Curtains
Standard Air Curtains
Recessed Air Curtains
Decorative, Bespoke and Customized Air Curtains
Air curtains with Disinfection and Purification System
Heat Pump and Energy Saving Air Curtains
Industrial Air Curtains and Cold Store Air Curtains
Insect control Air Curtains
Revolving Door and Tailor Made Air Curtains
Economic Low Cost Air Curtains

Technology
What is an air curtain?
How air curtains work?
Advantages and benefits of air curtains
Heat pump air curtains
EC air curtains
AirtĂšcnics air curtains
Ventilation

Downloads
Air curtains catalogues
Ventilation catalogues
BIM Air Curtains
Air curtains price list
Technical documentation
Quality certificates

Featured content
Clever advanced control
Air curtains selection program
Air curtains installations: References
Air curtains photo gallery
About us
AirtĂšcnics history
Rosenberg group
Contact
Outlet


Related Websites
Air Curtains
Rideaux d’air
Actuadores
Cortinas de aire
Luftschleier
EC Fans
Air Curtain Manufacturer
Barriere d’aria
Recuperadores de calor
Air Curtain Supplier
Luchtgordijnen
Rite Calidad Aire
Ilmaverho
Kurtyny Powietrzne
+34 93 715 99 88 +34 93 715 99 88
airtecnics@airtecnics.com

Request more information

The message been successfully submitted.

Request more information

If you want more information, fill the form and we contact with you.






Check this box if you like to receive professional information.

In accordance with the established RGPD (General Data Protection Regulation), we inform you that your personal data collected by means of this form will be incorporated in a file held by MOTORS I VENTILADORS, S.L., which has the purpose of enabling the management and commercial relations, informative or contractual and in any form and medium, including electronic means, about the products and/or services you are interested in. Your data will not be disclosed to third parties without your consent expressly stated, except in cases provided by law or requisitions of the competent public Administration.

You therefore expressly authorise us to use and process your personal data for the aforementioned purposes.

At any time, you may exercise your rights of access, rectification, erasure, restriction of processing, portability and object of your personal data processing. We request that you notify us to MOTORS I VENTILADORS, S.L. C/ Conca de Barberà, 6, Pol. Ind. Pla de la Bruguera 08211 CASTELLAR DEL VALLÈS (Barcelona) or send an email to the following address airtecnics@airtecnics.com

I accept and give my consent for the abovementioned purposes. (*)
